Professional and Reliable Dual-OS design to ensure high reliability of system running. ANR technology to enhance the storage reliability when the network is disconnected
HD Input
H.265/ H.265+/H.264//H.264+/MPEG4 video formats.Connectable to the third-party network cameras Up to 32 IP cameras can be connected.
Recording at up to 8 MP resolution. Supports live view, storage, and playback of the connected camera at up to 8 MP resolution.
HD Output
HDMI1/VGA1 and HDMI2/VGA2 independent outputs provided. HDMI1 Video output at up to 4K (3840 × 2160) resolution HD Storage Up to 8 SATA interfaces and 1 eSATA interface connectable for recording and backup. Storage space effectively saved by 50% to 70% with the use of H.264+ decoding format.
HD Transmission
2 self-adaptive 10 M/100 M/1000 Mbps network interfaces, and two working modes are configurable: multi-address and network fault tolerance.
Various Applications
Centralized management of IP cameras, including configuration, information import/export, real-time information display, two-way audio, upgrade, etc. Connectable to smart IP cameras from Hikvision and the recording, playing back, and backing up of VCA alarms can be realized.
- VCA detection alarm is supported
- Instant playback for assigned channel during multi-channel display mode
- Smart search for the selected area in the video; and smart playback to improve the playback efficiency
- Supports HDD quota and group modes; different capacity can be assigned to different channels
Specification:
| Network |
|---|
| Incoming bandwidth: |
|
256Mbps |
| Outgoing bandwidth: |
|
160Mbps |
| Video/Audio Output |
|---|
| HDMI/VGA output: |
|
4-ch, VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 ×1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz; HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560× 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 ×1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz; VGA2/HDMI2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×768/60Hz |
| Recording Resolution: |
|
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback: |
|
16-ch |
| Decoding |
|---|
| Capability: |
|
8-ch@1080P |
| Live view / Playback: |
|
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
| Hard Disk |
|---|
| eSATA: |
|
1 eSATA interface |
| SATA: |
|
8 SATA interfaces for 8 HDDs |
| Capacity: |
|
Up to 6TB capacity for each HD |
| External Interface |
|---|
| Network Interface: |
|
2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| Serial Interface: |
|
RS-232, RS-485, Keyboard |
| USB Interface: |
|
Front panel: 2 × USB 2.0
Rear panel: 1 × USB 3.0 |
| Alarm In: |
|
16-ch |
| Alarm Out: |
|
4-ch |
| General |
|---|
| Power Supply: |
|
100 to 240 VAC, 50 to 60 Hz |
| Power: |
|
200 W |
| Consumption(without hard disk and POE): |
|
≤ 30 W |
| Working Temperature: |
|
-10 oC ~ +55 oC (+14 oF~ + 131 oF) |
| Working Humidity: |
|
10 % ~ 90 % |
| Chassis: |
|
2U chassis |
| Dimensions: |
|
445 × 470 × 90 mm (17.5" × 18.5" × 3.5") |
| Weight(without HDD): |
|
≤ 8 kg (17.6 lb) |
| Video/Audio Input |
|---|
| Two-way audio input: |
|
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| IP video input: |
|
32-ch |
